| Herkunftsort: | Provinz Shandong, China |
|---|---|
| Markenname: | SH |
| Zertifizierung: | ISO9001,CE |
| Modellnummer: | SHJM350, SHJM650, SHJM800 |
| Min Bestellmenge: | 1 Set |
| Preis: | US $7,500-13,950 / Set |
| Verpackung Informationen: | Eisenrahmenverpackungs- oder -behälterladen |
| Lieferzeit: | innerhalb von 15 Tagen |
| Zahlungsbedingungen: | T/T, Western Union |
| Versorgungsmaterial-Fähigkeit: | 1000 Stück/Jahr |
| Name: | Präzision resaw Bandsäge | Zustand: | Neu |
|---|---|---|---|
| Typ: | Band sah | Hauptmotorleistung: | 15 kW, 18,5 kW, 22 kW |
| Fütterungsmotor: | 1,1 kW, 1,5 kW | Durchmesser der Säge: | 700 mm |
| Max. Sägebreite: | 800 mm | Max. Verarbeitungshöhe: | 220 mm |
| Fütterungsgeschwindigkeit: | Inverter, Geschwindigkeit justierbar | Garantie:: | 1 Jahr |
| Nachverkaufsservice erbracht: | On-line-Unterstützung, technische Videounterstützung, beauftragend und bildet aus | ||
| Hervorheben: | electric horizontal bandsaw sawmill,precision wood resaw machine,industrial horizontal sawing equipment |
||
For high-volume woodworking operations, achieving flawless, consistent cuts isn't just a goal—it's a necessity for profitability. An industrial precision resaw bandsaw is engineered to deliver exactly that: unparalleled accuracy and efficiency in every cut. This machine transforms raw lumber into high-value products by maximizing yield and ensuring a superior finish, directly boosting your bottom line through reduced waste and increased output.
Unmatched Cutting Accuracy & Consistency
Benefit: Produce glue-ready laminates and perfectly dimensioned lumber with exceptional smoothness, minimizing the need for secondary planing or sanding.
Features Behind the Benefit: A sophisticated fence system ensures precise workpiece positioning, while computer-balanced wheels and ultra-rigid construction eliminate vibration for dead-straight cuts.
Industrial-Grade Construction for Demanding Environments
Benefit: Experience rock-solid stability and durability that stands up to the rigors of continuous production, ensuring long-term reliability and minimal downtime.
Features Behind the Benefit: Built with heavy-duty components like solid cast-iron wheels, robust trunnions, and a large, stable cast-iron table that forms an unshakable foundation.
| Horizontal Resaw Band Saw Mills | |||
| Model | SH350 | SH650 | SH800 |
| Saw Wheel Diameter | 710 mm | 710 mm | 710 mm |
| Maximum Cutting Width | 350 mm | 650 mm | 800 mm |
| Maximum working Wood Height | 200 mm | 220 mm | 220 mm |
|
Max Sawing Height
|
100 mm | 110 mm | 110 mm |
|
Min Sawing Thickness
|
2 mm | 2mm | 2mm |
| Feeding speed | Variable Frequency Adjusted Speed | ||
| Main Electric Motor Power | 15 KW | 18.5 KW | 18.5KW |
| Up/down motor | 0.37kw | 0.37kw | 0.37kw |
| Feeding motor | 1.1kw | 1.1kw | 1.5kw |
| Machine Weight | 1000 KG | 1200 KG | 1400 KG |
![]()
![]()
Precision Slice Horizontal Band Sawmill
|
Model
|
SHJM-400
|
SHJM-650
|
SHJM-800
|
|
Saw Wheel Diameter
|
600MM
|
600MM
|
700MM
|
|
Max Sawing Wood Width
|
400MM
|
650MM
|
800MM
|
|
Max Sawing Height
|
110MM
|
||
|
Min Sawing Thickness
|
2MM
|
||
|
Feeding Speed
|
0.1-30 Meters/Minute
|
||
|
Motor Power
|
15KW
|
18.5KW
|
22KW
|
|
Feeding Motor
|
0.75KW |
0.75KW
|
1.5KW
|
![]()
![]()
This machine is purpose-built for industrial production settings, cabinet shops, and specialized mills focused on high-volume, precision work. If your operations involve frequently breaking down thick stock or require the ability to produce thin, consistent slices of wood with a flawless finish, a precision resaw is an indispensable asset.
